Bluewater Industries

Relaxn 20A Large Current Stainless Steel Push-Button Switch

Relaxn 20A Large Current Stainless Steel Push-Button Switch

$25.00 AUD
$25.00 AUD
Sale Sold out
Model

Relaxn 20A Large Current Stainless Steel Marine Push-Button Switches

Marine Grade Large Current (20A) Stainless Steel Push-Button Switch with LED Light Ring

FEATURES

  • Market-leading 20A Capability (No more relays!)
  • Same compact size as mainstream anti-vandal switches in market (PB-42 Series)
  • Durable CNC Stainless Steel (SS316) housing
  • 0.250” Quick connect terminals
  • LED light rings configurable to be push-on (power indication) or always on (back lighting)
  • IP67 – protected even under temporary water immersion
 Patented 20A Design
 IP67 Water proof even under temporary immersion

SPECIFICATION

  • Rating | DC 12V 20A / DC 24V 10A
  • Electrical Life | > 20,000 cycles
  • Operation Temperature | -20°C ~ +55°C

PRODUCT CODING

Product ID Voltage Rating LED Color Switch Function
SAW-530723-L-R DC 12V Red ON-OFF (Latching)
SAW-530723-M-R DC 12V Red (ON)-OFF (Momentary)
SAW-530721-L-B DC 12V Blue ON-OFF (Latching)
SAW-530721-M-R DC 12V Blue (ON)-OFF (Momentary)
